DESIGN FEATURES:
- Non-rising handwheel: Free from foreign substance trouble because most threaded surface is covered.
- No leakage by two-stage sealing of double bellows and gland packing.
- Gland packing does not need retightening nor applying pressure on spindle, thus handwheel can be turned with small torque without interference from the spindle.
- Maintenance-free: No need to replace or retighten gland packing.
TECHNICAL SPECIFICATIONS:
- APPLICATION: Steam, Air, Cold and hot water, Oil, Other non-dangerous fluids
- SIZES: ½” TO 8”
- MAXIMUM PRESSURE: UPTO 2.8 Mpa
- MAXIMUM TEMPERATURE: 3500C
- BODY MOC: Ductile Cast Iron
- BONNET: Ductile Cast Iron
- SEAT: SS
- BELLOW: SS
- END CONNECTIONS: Screwed and Flanged
